Performance and benefits:
1. Pipe in line with CJ/T270-2007 standard;
2. Safe and reliable, high ring stiffness. The inner wall smooth flow resistance is 20-30% lower than the cement pipe resistance
3. Flexible or leak-free connection (electric fusion welding, stainless steel clamp);
4. Light weight, few joints, no need for large installation equipment, convenient installation and laying;
5. Corrosion resistance, service life of more than 50 years.
model | Pipe Diameter (mm) | extruder | Strip forming speed (m/min) | Total installed power (KW) |
ZJSG-1500 | 200-1500 | ZJS65/33 ZJS45/33(7.5kw) | 4-6 | 150 |
ZJSG-1800 | 600-1800 | ZJS75/33 ZJS45/33(11kw) | 3.5-5 | 180 |
ZJSG-2400 | 1000-2400 | ZJS90/33 ZJS45/33(22kw) | 3-4 | 200 |
ZJSG-3000 | 1500-3000 | ZJS90/33 ZJS65/33(37kw) | 2.5-4.5 | 230 |
